OMPG submersible agitors

Series: S 100 – R 160 und X 132- X 160


  • high quality helical, welded two-bladed propellers with great thrust and high throughput
  • type: fine-grained steel S355 or stainless steel 1.4401 in various sizes and designs depending on the application
  • Viton seals and different epoxy resin coatings for media down to pH2 possible as option
  • various motors for different voltages, frequencies, insulation classes available
  • power range: 1.1 kW to 18.5 kW (electrical connected load)
  • with planetary gear
  • speed electric motor: 1450/ min
  • power class 7.5 kW to 18.5 kW optionally available in ATEX design
  • leakage sensor with oil bath with double mechanical seal
  • generously dimensioned catching device (catching bracket)
